- Model: ST-1124G
- Chipset: Realtek/RTL8382L
- Transmission Rate: 10/100/1000Mbps
- Switching Capacity: 48Gbps
- Packet Forwarding Rate: 32.8Mpps
- MAC Address Table: 8K
- Communication Mode: Full-Duplex & Half-Duplex
- Standards and Protocols: IEEE 802i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p
- Interface: 24 10/100/1000Mbps RJ45 Ports, Auto Negotiation/Auto MDI/MDIX
- Forwarding Mode: Store-and-Forward
- Network media: 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) & 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
- Power Supply: AC Power: 100-240VAC, 50/60Hz
- 802.1p/DSCP QoS: Yes
- LED: Power, 1000Mbps, Link/Act
- Cooling Fan: Yes
- Jumbo Frame: 10KB
- Dimension: 440*220*45MM
- Maximum Power Consumption: (220V/50Hz) 9.26W
- Certifications: CE, FCC, RoHS
- Operating Temperature: 0°C~40°C(32°F~104°F)
- Storage Temperature: -40°C~70°C(-40°F~158°F)
- Operating Humidity: 10%~90%RH non-condensing
- Storage Humidity: 5%~90%RH non-condensing
- Body type & color: Metal body / Black
